intra<em>HEAL</em> Reamed Tibial Nail

intraHEAL Reamed Tibial Nail

Model No.: ITL08-14
Product Availability: In Stock

The GPC tibial nail is indicated in open & closed tibial shaft fractures, tibial malunion and nonunions. They are available in stainless steel and titanium. Interlocking nail is available in length ranging from 22-44cm(1cm increments) and diameter from 9-14mm(1mm increments).It has two proximal locking options and three distal locking options.

Request a Quote Request a Catalogue
Superior
Quality
Affordable
Pricing
Timely
Shipment
Customer
Satisfaction

  • Open & closed tibial shaft fracture
  • Mal-unions/non-unions of the tibial shaft
  • Open/comminuted fracture of the tibia shaft
  • Pathological fracture
  • Tibia & fibula shaft fracture
  • Pseudoarthrosis
  • Tumor resection
  • Corrective Osteotomies

  • Static and dynamic locking options
  • Biplanar distal locking options provide rotational stability
  • Small caliber, cannulated implant inserted after reaming helps in reducing the hoop stress formation
  • 10 degree Herzog bend in proximal third of nail
  • Stability is increased with the reamed technique, because the nail fits snugly in a longer portion of the tibial shaft
  • Universal nail for right & left tibia
  • Available in both titanium and stainless steel


Length (mm) Code for Dia. (mm)  S.S.
8 9 10 11 12 13 14
220 ITL08.22 ITL09.22 ITL10.22 ITL11.22
230 ITL08.23 ITL09.23 ITL10.23 ITL11.23
240 ITL08.24 ITL09.24 ITL10.24 ITL11.24
250 ITL08.25 ITL09.25 ITL10.25 ITL11.25
260 ITL08.26 ITL09.26 ITL10.26 ITL11.26 ITL12.26 ITL13.26 ITL14.26
270 ITL08.27 ITL09.27 ITL10.27 ITL11.27 ITL12.27 ITL13.27 ITL14.27
280 ITL08.28 ITL09.28 ITL10.28 ITL11.28 ITL12.28 ITL13.28 ITL14.28
290 ITL08.29 ITL09.29 ITL10.29 ITL11.29 ITL12.29 ITL13.29 ITL14.29
300 ITL08.30 ITL09.30 ITL10.30 ITL11.30 ITL12.30 ITL13.30 ITL14.30
310 ITL08.31 ITL09.31 ITL10.31 ITL11.31 ITL12.31 ITL13.31 ITL14.31
320 ITL08.32 ITL09.32 ITL10.32 ITL11.32 ITL12.32 ITL13.32 ITL14.32
330 ITL08.33 ITL09.33 ITL10.33 ITL11.33 ITL12.33 ITL13.33 ITL14.33
340 ITL08.34 ITL09.34 ITL10.34 ITL11.34 ITL12.34 ITL13.34 ITL14.34
350 ITL08.35 ITL09.35 ITL10.35 ITL11.35 ITL12.35 ITL13.35 ITL14.35
360 ITL08.36 ITL09.36 ITL10.36 ITL11.36 ITL12.36 ITL13.36 ITL14.36
370 ITL08.37 ITL09.37 ITL10.37 ITL11.37 ITL12.37 ITL13.37 ITL14.37
380 ITL08.38 ITL09.38 ITL10.38 ITL11.38 ITL12.38 ITL13.38 ITL14.38
390 ITL08.39 ITL09.39 ITL10.39 ITL11.39 ITL12.39 ITL13.39 ITL14.39
400 ITL08.40 ITL09.40 ITL10.40 ITL11.40 ITL12.40 ITL13.40 ITL14.40
410 ITL08.41 ITL09.41 ITL10.41 ITL11.41 ITL12.41 ITL13.41 ITL14.41
420 ITL08.42 ITL09.42 ITL10.42 ITL11.42 ITL12.42 ITL13.42 ITL14.42
430 ITL08.43 ITL09.43 ITL10.43 ITL11.43 ITL12.43 ITL13.43 ITL14.43
440 ITL08.44 ITL09.44 ITL10.44 ITL11.44 ITL12.44 ITL13.44 ITL14.44

For Titanium, please affix 'T' after above code number.
